Force Gauge

Force gauge Sauter FK 500

The Sauter FK 500 is a force gauge that can measure both tensile and compressive forces in a wide range of applications. With optional fittings, it is perfectly adapted to different environments. The gauge has a clear display with 18 mm digit height. The peak value function (PEAK) and the hold function allow for the instrument's diverse applications. The instrument is supplied with a power supply, batteries (6 x 1.5V AA), and a basic connection accessory kit. NOTE! The Sauter FK range covers a total of 7 different versions with capacities from 10 to 1000 N. The online store lists models with capacities of 100 N, 500 N, and 1000 N, but other model versions are also available. Please ask your dealer or your nearest Megacenter for more information.

Functions:
- Measurement of tensile and compressive force
- Unit switching
- Peak hold function (PEAK)
- Hold function (HOLD)
- Automatic shutdown (saves battery)

Basic features:
- Measuring range 0-500 N
- Reading accuracy of ±0.2 N
- Measurement error maximum ±0.5 % of maximum
- Overload protection 200 % of maximum
- Internal measuring frequency 1000 Hz
- Units of measurement N, lbf, kg, ozf
- Battery operation (6 x 1.5V AA) or power supply

Operating conditions:
- Operating temperature 10-30°C

Accessories, available separately:
- Factory calibration for tensile force
- Factory calibration for compression force
- Factory calibration for both tensile and compression
- Wide range of different fittings
- Manual or automatic test stand
